| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0126 is a 2-pole thermal circuit breaker designed for equipment protection. It features rocker actuation and a panel mount type, suitable for various industrial applications.
This circuit breaker operates with a thermal tripping mechanism and offers thermal-magnetic tripping for short-circuit protection. It has a rated voltage of 240 VAC IEC and 277 VAC UL/CSA, with a DC rating of 60 VDC. The rated current range is from 0.05 to 20 A AC, with magnetic tripping up to 16 A. The conditional short circuit capacity is 2 kA at 240 VAC.
Key specifications include a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30 °C to 60 °C. The front side offers IP40 protection. Applications include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
It is available with green illumination and a nominal illumination voltage of 240V. The device is designed for reliable operation in demanding environments.
It is rated for 240VAC (IEC), 277VAC (UL/CSA), and 60VDC.
The operating temperature range is -30°C to 60°C.
Panel mount.
It uses thermal and thermal-magnetic tripping.
50,000 switching cycles.
Greater than 2.5 kV at 50 Hz.
IP40 according to IEC 60529.
