| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0365 is a 2-pole thermal circuit breaker suitable for various industrial applications. It offers a rated current of 2A and operates at AC voltages up to 240 VAC and DC voltages up to 60 VDC.
This circuit breaker features thermal tripping and rocker actuation, providing reliable short-circuit protection. It is designed for panel mounting and has a mechanical lifetime of 50,000 switching cycles. The operating temperature range is from -30 °C to 60 °C.
Key specifications include a conditional short circuit capacity of 2 kA at 240 VAC and an ingress protection rating of IP40 on the front side. The device also meets RoHS3 compliance and has an MSL of 1.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The Schurter 4435.0365 is rated for 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
The allowable operating temperature range is -30 °C to 60 °C.
This circuit breaker is panel mounted.
The dielectric strength is greater than 2.5 kV at 50 Hz.
The mechanical lifetime is 50,000 switching cycles.
