| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0366 is a 2-pole thermal circuit breaker with a rocker actuation type. It is designed for panel mounting and offers a current rating range of 0.05 to 20 A AC, with a magnetic trip up to 16 A. The rated voltage is 240 VAC IEC and 277 VAC UL/CSA, with a DC rating of 60 VDC.
This circuit breaker has a conditional short circuit capacity of 2 kA at 240 VAC. It features a degree of protection of IP40 on the front side, dielectric strength greater than 2.5 kV, and impulse dielectric strength greater than 4 kV. The insulation resistance is over 100 MΩ at 500 VDC.
Mechanical lifetime is rated for 50,000 switching cycles. The operating temperature range is -30 °C to 60 °C, and storage temperature is -40 °C to 60 °C. It meets vibration resistance standards up to 10 G and shock resistance of 30 G / 18 ms.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated current is 8A.
It supports 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
It has 2 poles.
It uses a rocker actuator.
The operating temperature range is -30 °C to 60 °C.
The mechanical lifetime is 50,000 switching cycles.
