| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.014 is a 2-pole thermal circuit breaker suitable for various industrial applications. It offers a rated current of 10A and can operate at AC voltages up to 240V and DC voltages up to 60V.
This circuit breaker features a rocker actuation type and a panel mount design for easy integration into equipment. It provides thermal tripping and is rated for a conditional short circuit capacity of 2 kA at 240 VAC. The device has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30°C to 60°C.
Key specifications include a dielectric strength of over 2.5 kV and an impulse dielectric strength of over 4 kV. The insulation resistance is greater than 100 MΩ at 500 VDC. Approvals include CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated current for the Schurter Inc. 4435.014 circuit breaker is 10A.
The maximum AC voltage rating for this circuit breaker is 240 VAC.
The Schurter Inc. 4435.014 circuit breaker has 2 poles.
The allowable operating temperature range for this circuit breaker is -30 °C to 60 °C.
The Schurter Inc. 4435.014 circuit breaker uses rocker actuation.
