| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0116 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 3A and operates at up to 240VAC or 60VDC. The breaker features a positively trip-free release mechanism and rocker actuation, making it suitable for various industrial and commercial applications.
With a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30°C to 60°C, this circuit breaker is built for durability. It meets IP40 protection standards on the front side and has a conditional short circuit capacity of 2 kA at 240 VAC. The panel mount design ensures easy integration into equipment.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. Its thermal tripping type provides protection against overloads, while the option for thermal-magnetic tripping offers enhanced short-circuit protection.
Key technical data includes a dielectric strength of >2.5 kV and an insulation resistance of >100 MΩ. The unit weighs 32g (magnetic module 56g).
The rated voltage is 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 60 VDC.
The rated current range is 0.05 to 20 A AC, with a magnetic tripping capability up to 16 A.
The allowable operating temperature is from -30°C to 60°C.
The RoHS status is RoHS3 Compliant.
