The SMBJ130A from TSC is a surface mount Transient Voltage Suppressor (TVS) diode housed in a DO-214AA (SMB) package. It is designed to protect electronic circuits from transient voltage events.
Key electrical characteristics include a working standoff voltage of 130V and a breakdown voltage typically starting at 6.40V. The device can handle a peak pulse power of 600W with a 10/1000μs waveform, and a maximum clamping voltage of 9.6V at 65.0A peak impulse current. It operates over a junction temperature range of -55°C to +150°C.
This TVS diode is suitable for automated placement and is ideal for applications such as switching mode power supplies (SMPS). It features a glass-passivated junction, built-in strain relief, and fast response time.
The SMBJ130A is compliant with RoHS Directive 2011/65/EU and WEEE 2002/96/EC, and is halogen-free according to IEC 61249-2-21.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The SMBJ130A has a peak pulse power dissipation of 600W with a 10/1000μs waveform.
The working standoff voltage for the SMBJ130A is 130V.
The breakdown voltage of the SMBJ130A is a minimum of 6.40V and a maximum of 7.30V at 10mA test current.
The maximum clamping voltage for the SMBJ130A is 9.6V at a peak impulse current of 65.0A.
The SMBJ130A is available in the DO-214AA (SMB) package.
The SMBJ130A operates over a junction temperature range of -55°C to +150°C.
