The Schurter Inc. 4435.0077 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 15A and operates at up to 240 VAC and 60 VDC.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC and an insulation resistance greater than 100 MΩ at 500 VDC. The breaker has a mechanical lifetime of 50,000 switching cycles and provides thermal tripping.
This circuit breaker is suitable for panel mounting and features rocker actuation. It operates within a temperature range of -30 °C to 60 °C and has a degree of protection of IP40 on the front side.
Applications for this component include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated voltage is 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 60 VDC.
The rated current range is 0.05 - 20 A AC, with a magnetic rating up to 16 A.
This circuit breaker has 2 poles.
The allowable operation temperature is from -30 °C to 60 °C.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
The REACH status is REACH Unaffected.
