| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.0188 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 15A and operates at up to 240 VAC and 60 VDC.
This circuit breaker features a thermal tripping type and a rocker actuation for ease of use. It is designed for panel mounting, making it suitable for integration into various equipment and systems. The device also includes illumination with a green indicator and a nominal voltage of 240V.
Key technical specifications include a conditional short circuit capacity of 2 kA at 240 VAC, an IP40 degree of protection on the front side, and a wide operating temperature range from -30 °C to 60 °C. The mechanical lifetime is rated at 50,000 switching cycles.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances, among others. Its robust design and specific ratings make it a versatile component for demanding environments.
The Schurter 4435.0188 is rated for 15A continuous current.
It is rated for 240 VAC (IEC) / 277 VAC (UL/CSA) and 60 VDC.
The allowable operating temperature range is -30 °C to 60 °C.
It uses a rocker actuator with green illumination.
The Schurter 4435.0188 is designed for panel mounting.
