APA501-80-003
Artesyn Embedded Power
Heatsink for AMPSS power modules, 80 size, vertical fin orientation, 115x59x22.5mm dimensions, 2.2°C/W free air thermal resistance, through-hole mounting.
| Category | |
| Manufacturer Name | |
| Mounting Type |
The Vicor EN1TN2 is a DC-DC regulated power supply module with a part number EN1TN2. It operates within an input voltage range of 180V to 264V, with a nominal input of 230V. The module provides an output voltage ranging from 250V to 375V and can deliver a maximum total power output of 575W.
Designed for industrial applications, this module has an operating temperature range of -40°C to 100°C. It features 9 terminations and a terminal pitch of 10.16mm. The dimensions of the module are 57.9mm in length and 55.9mm in width. The terminal finish is Gold (Au) with a Nickel (Ni) barrier.
This component is classified as a DC-DC REGULATED POWER SUPPLY MODULE and utilizes HYBRID technology. It is not designed for surface mounting and has a PIN/PEG terminal form. The part status is active.
180V to 264V AC, with nominal 230V.
250V to 375V DC.
575W.
-40°C to 100°C.
Through-hole with 9 pins.
Gold with nickel barrier.
