| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.0358 is a 2-pole thermal circuit breaker designed for equipment protection. It features thermal-magnetic tripping and rocker actuation, offering a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and 60 VDC.
The current rating ranges from 0.05 A to 20 A AC, with magnetic tripping up to 16 A. This circuit breaker has a conditional short-circuit capacity of 2 kA at 240 VAC according to IEC 60934. It operates within a temperature range of -30 °C to 60 °C and has a mechanical lifetime of 50,000 switching cycles.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. It offers a degree of protection of IP40 on the front side and meets stringent dielectric strength and insulation resistance requirements.
Mounting is via a panel mount configuration. The device is built for durability, with resistance to vibration and shock, and a thermal tripping mechanism. It is available with various illumination options, including green.
The Schurter 4435.0358 is rated for 240 VAC (IEC) and 277 VAC (UL/CSA) as well as 60 VDC.
The allowable operating temperature range is -30 °C to 60 °C.
The front side of the circuit breaker has an IP40 degree of protection according to IEC 60529.
The mechanical lifetime is 50,000 switching cycles.
The dielectric strength is greater than 2.5 kV at 50 Hz and greater than 4 kV for a 1.2/50 μs impulse.
