| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating |
This Schurter Inc. 4435.0158 is a 2-pole thermal circuit breaker suitable for panel mounting. It operates with a 5A current rating and is designed for AC applications up to 240 VAC and DC up to 60 VDC.
The breaker utilizes a thermal tripping mechanism and features a rocker actuator for operation. It offers a mechanical lifetime of 50,000 switching cycles and an AC/DC electrical lifetime of 50,000 switching cycles under specified conditions. The device has a conditional short circuit capacity of 2 kA at 240 VAC and provides IP40 protection on the front side.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. Its robust design and thermal protection make it suitable for various industrial and commercial equipment.
The rated current is 5A.
It is rated for 240VAC and 60VDC.
It has a green illuminated rocker actuator.
It is a 2-pole circuit breaker.
The operating temperature range is -30°C to 60°C.
It has an IP40 degree of protection according to IEC 60529.
It is designed for panel mounting.
