| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0214 is a 2-pole thermal circuit breaker suitable for various industrial applications. It offers a rated current range from 0.05A to 20A (magnetic up to 16A) and a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA), with a DC rating of 60 VDC.
This circuit breaker features thermal-magnetic tripping and rocker actuation, with a mechanical lifetime of 50,000 switching cycles. It has a degree of protection of IP40 on the front side and operates within an ambient temperature range of -30°C to 60°C.
Designed for applications such as power tools, medical equipment, and industrial appliances, the 4435.0214 provides reliable short-circuit protection. It is panel-mounted and offers a high degree of configurability in terms of rocker colors and lettering, though specific options are not detailed here.
The breaker is rated for 240 VAC under IEC standards, 277 VAC under UL/CSA standards, and 60 VDC.
The unit utilizes a panel mount configuration with a rocker actuation type for manual operation.
The device operates reliably within a temperature range of -30 °C to 60 °C.
The 4435.0214 guarantees a lifetime of 50,000 switching cycles for both mechanical operation and AC/DC electrical loads.
It provides a minimum of 40 overload trips per IEC standards and 50 trips per UL/CSA standards.
The front side of the unit meets an IP40 degree of protection according to IEC 60529 standards.
