| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.0104 is a 2-pole thermal circuit breaker designed for panel mounting. It features rocker actuation and a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA), with a DC rating of 60 VDC.
This circuit breaker has a rated current range of 0.05 to 20 A AC, with magnetic tripping up to 16 A. It offers a conditional short circuit capacity of 2 kA at 240 VAC. The front side has an IP40 degree of protection according to IEC 60529.
Key electrical specifications include a dielectric strength of over 2.5 kV at 50 Hz and over 4 kV impulse, with an insulation resistance greater than 100 MΩ at 500 VDC. Mechanical lifetime is rated at 50,000 switching cycles. The operating temperature range is -30 °C to 60 °C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
It supports 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
The AC current range is 0.05 to 20 A (magnetic trip up to 16 A).
It operates from -30°C to 60°C and can be stored from -40°C to 60°C.
It is rated IP40 according to IEC 60529.
Yes, it supports both thermal and thermal-magnetic tripping types.
It has a mechanical lifetime of at least 50,000 switching cycles.
The conditional short-circuit current rating (Inc) is 2 kA at 240 VAC (IEC 60934).
