| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0112 is a 2-pole thermal circuit breaker designed for equipment protection. It features rocker actuation and a thermal-magnetic tripping mechanism, providing reliable short-circuit protection.
This circuit breaker has a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and a DC rating of 60 VDC. The AC current range is from 0.05 to 20 A, with magnetic tripping up to 16 A. It offers a conditional short circuit capacity of 2 kA at 240 VAC.
With a mechanical lifetime of 50,000 switching cycles, the 4435.0112 is built for durability. It operates within a temperature range of -30 °C to 60 °C and has a degree of protection of IP40 on the front side.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, equipment for construction, cleaning equipment, and commercial/household kitchen appliances. Its snap-in version and configurable options make it a versatile choice for various designs.
240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
-30 °C to 60 °C.
Panel Mount.
Thermal tripping.
Mechanical and electrical lifetimes are 50,000 switching cycles.
Yes, it has a red illuminated rocker actuator with a nominal voltage of 240 V.
Front side IP40 according to IEC 60529.
