| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0044 is a thermal circuit breaker designed for equipment protection. This 3-pole device features a rocker actuation type and a panel mount for easy integration into various systems.
Key electrical specifications include a rated voltage of 240 VAC and a current rating range of 0.05 to 12 A, with this specific model rated at 5A. It offers a conditional short circuit capacity of 2 kA at 415 VAC. The breaker is built for durability, with a mechanical lifetime of 50,000 switching cycles.
Environmental and operational parameters include an operating temperature range of -30 °C to 60 °C and a storage temperature range of -40 °C to 60 °C. The front side offers an IP40 degree of protection. The device is designed according to standards such as IEC 60934 and UL 1077.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. Its robust design and thermal tripping mechanism ensure reliable protection against overcurrent conditions.
415 VAC (also 240 VAC).
-30 °C to 60 °C.
5A (adjustable range 0.05-12 A).
Rocker actuator.
3 poles.
Panel mount.
>2.5 kV at 50 Hz and >4 kV impulse.
