| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter 4435.0071 is a 3-pole thermal circuit breaker featuring rocker actuation and panel mount capability. It operates with a rated voltage of 240V AC and is designed for applications requiring reliable overcurrent protection.
This circuit breaker offers a wide rated current range from 0.05A to 12A, with a specific 5A rating noted in the product data. It has a conditional short-circuit capacity of 2 kA at 415 VAC and a mechanical lifetime of 50,000 switching cycles. The operating temperature range is -30°C to 60°C.
Key features include a positively trip-free release mechanism and thermal tripping type. The ingress protection rating for the front side is IP40. Applications for this series include power tools, medical equipment, industrial appliances, and construction equipment.
Compliance data indicates RoHS3 compliance, MSL 1, and REACH unaffected status, though these are noted as low confidence due to source verification.
The rated voltage is 415Y/240 VAC.
The operating temperature range is -30°C to 60°C.
The rated current range is 0.05 to 12 A, with a specific rating of 5A.
It is a 3-pole circuit breaker.
The conditional short circuit capacity is 2 kA at 415 VAC.
Dielectric strength is greater than 2.5 kV at 50 Hz and greater than 4 kV impulse.
The mechanical lifetime is 50,000 switching cycles.
