| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0111 is a 3-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current range of 0.05 to 12A and a rated voltage of 415Y/240 VAC. This breaker features a rocker actuation type and a panel mount design for easy integration into equipment.
Key specifications include a conditional short circuit capacity of 2 kA @ 415 VAC, IP40 degree of protection on the front side, and a dielectric strength of >2.5 kV. The device has a mechanical lifetime of 50,000 switching cycles and operates within a temperature range of -30°C to 60°C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. Its thermal tripping type ensures safe operation under overload conditions.
The breaker is rated for 240VAC (line-to-neutral) and 415Y/240 VAC (three-phase system).
-30°C to 60°C.
5A continuous.
3 poles.
Thermal tripping.
Rocker actuator.
2 kA at 415 VAC per IEC 60934.
