| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4430.2867 is a 2-pole thermal circuit breaker designed for reliable overload protection. It features a rocker actuation type and a panel mount design, making it suitable for various industrial applications.
This circuit breaker operates with a rated voltage of 240 VAC and 60 VDC, with a rated current range of 0.05 to 20 A AC. It provides a conditional short circuit capacity of 1 kA at 240 VAC and a short circuit capacity of up to 300A at 240 VAC. The device is built for durability, offering a mechanical lifetime of 50,000 switching cycles.
Environmental specifications include a degree of protection of IP40 on the front side, which can be increased to IP54 with a factory-mounted protection cover. The operating temperature range is -10 °C to 55 °C. Approvals from VDE, UL, and CCC are listed, indicating compliance with relevant safety standards.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment. Its thermal tripping mechanism ensures positive trip-free release and high configurability.
The breaker is rated for 240 volts AC and 60 volts DC.
The unit functions reliably within a temperature range of -10 degrees Celsius to 55 degrees Celsius.
The device maintains a mechanical and electrical lifetime of 50,000 switching cycles at rated current.
It offers a conditional short-circuit capacity of 1 kiloampere per IEC 60934, with a maximum interrupting capacity of 300 amperes.
Yes, it features a red illumination indicator that operates at a nominal 110 volts.
The base unit provides IP40 protection, which increases to IP54 when a factory-mounted protection cover is installed.
