The Schurter Inc. 4430.1366 is a 2-pole thermal circuit breaker suitable for panel mounting. It offers a rated voltage of 240 VAC and 60 VDC, with a current rating range of 0.05 to 20 A, specifically rated at 5A for this model.
This circuit breaker provides thermal overload protection and features a positively trip-free release mechanism. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -10 °C to 55 °C. The degree of protection is IP40, or IP54 with a factory-mounted protection cover.
Key electrical specifications include a conditional short circuit capacity of 1 kA and a short circuit capacity of up to 300A. It also boasts a dielectric strength of 4 kVAC and an insulation resistance greater than 100 MΩ at 500 VDC.
Applications for this type of circuit breaker include power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment. The actuation type is a rocker, and this specific model features red illumination with a nominal voltage of 110V.
The rated voltage is 240 VAC and 60 VDC.
The current rating is 5A.
It has 2 poles.
It uses rocker actuation.
The allowable operation temperature is -10 °C to 55 °C.
