The Cinch 10-141 is a Series 141 double-row barrier block designed for industrial power distribution and control applications. It features 10 circuits with a 0.438" (11.12mm) center-to-center spacing and accepts up to 14 AWG wire. The block is rated for 250VAC RMS maximum and 20 Amps maximum, with a maximum power dissipation of 5000W per terminal.
Constructed with a molded monoblock black phenolic insulation rated UL94V-1, the block uses brass nickel-plated terminals and steel nickel-plated screws (6-32 x 1/4"). The combination/binder head screw design provides reliable top termination. Recommended screw torque is 14 lb-in, and mounting hole torque is 7 lbs.
The barrier block features interposing barriers between terminals for higher electrical ratings and protection against short circuits. It is designed for chassis or panel mounting using the integral flange. The operating temperature range is -55°F to +300°F (-48°C to +149°C).
The 10-141 has 10 circuits arranged in 2 rows.
The pitch is 0.438" (11.12mm) center-to-center.
The voltage rating is 250VAC RMS maximum, and the current rating is 20 Amps maximum.
The maximum wire size is 14 AWG.
The operating temperature range is -55°F to +300°F (-48°C to +149°C).
Top termination uses screws (6-32 x 1/4" combination/binder head). Bottom termination is open per the datasheet.
The insulation is molded black phenolic rated UL94V-1.
