Mfr Part #:

TWR-S08PT60

TWR-S08PT60 is a Tower System daughter card for the 5-volt 8-bit MC9S08P family of MCUs from NXP. It provides an evaluation platform with HCS08 core processor, including board(s) and cable(s).

✓ Total Stock: 5,000 pcs

$ Price Range: $149.03

TWR-S08PT60 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Components Technology Group, Inc. ✓ Non-Authorised Inventory information	5,000 pcs On Request	5000 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

TWR-S08PT60 Description

Short technical summary and product information.

The TWR-S08PT60 is a Tower System daughter card from NXP Semiconductors designed for the 5-volt, 8-bit MC9S08P family of microcontrollers. This evaluation platform features the HCS08 core processor and is intended for rapid prototyping and tool re-use through the reconfigurable Tower System hardware. The board includes on-board debug interface, a potentiometer, reset switch, MMA8451Q accelerometer, and capacitive touch pads.

The TWR-S08PT60 can function as a stand-alone, low-cost evaluation platform for MC9S08PT60 devices or be used in conjunction with the TWR-S08UNIV Tower System module for expanded functionality. The board is fixed-mounted and comes with necessary cables for connectivity. It is ideal for industrial and home appliance applications where 5-volt 8-bit MCU performance is required.

Contents include the board and cables, and the board is RoHS3 compliant. The part is part of the NXP Tower System modular development platform, enabling scalable and reusable development tools.

TWR-S08PT60 Quick Information

Product Type: Evaluation Board for MCU

Series: MC9S08P

Canonical Name: TWR-S08PT60 Tower System Daughter Card for MC9S08P Family

Subcategory: MCU Evaluation Board

TWR-S08PT60 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TWR-S08PT60 Estimated Pricing

Qty	Low	High
1+	$149.03	$149.03

Estimated market price range - modelled values for guidance only, not live distributor offers.

TWR-S08PT60 Features

8-bit MCU with HCS08 core processor.
Tower System modular evaluation platform.
Designed for MC9S08P family devices.
Includes board and cables for connectivity.
On-board debug and sensor interfaces.

TWR-S08PT60 Applications

Industrial control system prototyping.
Home appliance MCU evaluation.
8-bit MCU development and testing.
Sensor integration projects.

TWR-S08PT60 FAQs

7 frequently asked questions generated from this part’s specifications.

Is the TWR-S08PT60 RoHS compliant?

Yes, it is RoHS3 compliant.

What core processor does the TWR-S08PT60 use?

HCS08.

What platform does the TWR-S08PT60 belong to?

Tower System.

What type of board is the TWR-S08PT60?

Evaluation Platform.

Which microcontroller is used on the TWR-S08PT60?

MC9S08P series.

What is included with the TWR-S08PT60?

Board(s) and cable(s).

What is the mounting type of the TWR-S08PT60?

Fixed.

TWR-S08PT60 Alternate Parts

Same form/fit/function or matching attribute configuration across different manufacturers.

View All Alternate Parts

TWR-S08PT60-KIT

NXP Semiconductors

Tower System daughter card evaluation board for NXP's 5V 8-bit MC9S08P family MCU. Features touch-sensing interface, accelerometer, potentiometer, and LEDs.

View Part

TWR-S08DC-PT60
