| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
252 pcs
|
252 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuation Force | |
| Actuator Marking | |
| Actuator Type | |
| Circuit | |
| Contact Resistance | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Operating Temperature | |
| Switch Function | |
| Termination Style | |
| Type | |
| Voltage Rating |
The E-Switch TL4201EEYA is a subminiature pushbutton switch designed for through-hole mounting. It features a 4PDT circuit configuration and a PC Pin termination style.
This switch is rated for 100mA at 30VDC and has an electrical life of 10,000 cycles. It supports both latching and momentary functions, providing flexibility for various applications. The actuator is a plunger type designed for use with a cap, and it offers a long travel of 2.5mm.
The operating temperature range is -20°C to 70°C. The TL4201EEYA series is suitable for applications requiring reliable switching in a compact form factor, such as instrumentation, consumer electronics, and medical equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The TL4201EEYA pushbutton switch is rated for 100mA at 30VDC.
The TL4201EEYA switch uses a through-hole mounting type.
The operating temperature range for the TL4201EEYA is -20°C to 70°C.
The TL4201EEYA is RoHS3 Compliant.
The TL4201EEYA features a 4PDT circuit configuration.
Yes, the TL4201EEYA offers both latching or momentary function.
