| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Color | |
| Current | |
| Current Rating | |
| Features | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Storage Temperature | |
| Style | |
| Tape & Reel | |
| Type | |
| Voltage |
The Opto 22 SNAP-OAC5 is a 4-channel digital output module designed for switching AC loads. Each channel supports a voltage range of 12-250 VAC and can handle up to 3 amps. This module utilizes zero voltage turn-on and zero current turn-off technology, ensuring transient-free switching for connected loads.
Part of the SNAP PAC System, the SNAP-OAC5 integrates seamlessly with SNAP PAC racks and brains or rack-mounted controllers. It is suitable for use in PC-based control systems or as intelligent remote I/O for Allen-Bradley Logix PLC systems. The module features removable top-mounted connectors for easy field wiring and includes channel-specific LEDs for convenient troubleshooting and maintenance.
Key electrical specifications include a 500V peak blocking voltage, a minimum load current of 20 mA, and an output voltage drop of 1.6V maximum at 0.75A. The operating frequency range is 25-65 Hz, with an off-state dV/dt of 200 V/ms. The module is powered by a single 5 VDC supply and offers 4000V of transient protection. It is designed for industrial environments with an operating temperature range of -20 to 70 °C.
| Qty | Low | High |
|---|---|---|
| 1+ | $104.00 | $104.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage range is 12-250 VAC.
Each channel is rated for 3 amps.
AC outputs use zero voltage turn on and zero current turn off for transient-free switching.
The operating temperature range is -20 to 70 °C.
Channel-to-channel isolation is not applicable for this module.
The module is powered by a single 5 VDC supply.
