SGM6603-5.0YN6G/TR
SG Micro Corp
The SG Micro Corp SGM6603-5.0YN6G/TR is a synchronous boost switching regulator. It features a 0.9V to 5.5V input voltage range and a fixed 5.0V output voltage.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,238 pcs
|
3238 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Efficiency | |
| Mounting Type | |
| Operating Temperature Range | |
| Tape & Reel |
The SGM3766YTN5G/TR is a 38V high-efficiency boost white LED driver manufactured by SG Micro Corp. It features a 1.2MHz fixed switching frequency and an integrated 40V/2.75A switch FET, making it suitable for powering single or parallel LED strings in various panel backlighting sizes.
This LED driver is capable of driving up to 10 white LEDs in series. It offers PWM dimming control, with the feedback voltage regulated at 200mV typically. The default LED current is set by an external RSET resistor. The device integrates LED open protection to prevent damage from over-voltage conditions during LED open scenarios.
Key features include an input voltage range of 2.7V to 5.5V, up to 90% efficiency, and automatic soft-start for reduced inrush current. It also provides stable luminance dimming with a ratio of 1:500, low EMI, and improved PSRR for waveless lighting. Protection features include over-voltage protection, under-voltage lockout, and thermal shutdown.
The SGM3766YTN5G/TR is available in a green TSOT-23-5 package and operates within an ambient temperature range of -40℃ to +85℃. It is designed for applications such as smartphone and tablet backlighting, handheld computers, PDAs, and GPS receivers.
The input voltage range is 2.7V to 5.5V.
The switching frequency is 1.2MHz.
The typical feedback voltage is 200mV.
The operating temperature range is -40℃ to +85℃.
It is available in a TSOT-23-5 package.
Yes, it supports PWM dimming control.
