Mfr Part #:

SDR-480-48

Name: SDR-480-48
Brand: Antaira Technologies
SKU: SDR-480-48

Description:

480 Watt Series / 48 VDC / 10.0

Stock on Request

SDR-480-48 Description

Short technical summary and product information.

480 Watt Series / 48 VDC / 10.0

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	AC DC Converters
Manufacturer Name	Antaira Technologies
Applications	Industrial, ITE (Commercial)
Approval Agency	CB, CE, cULus, EAC, TUV, UKCA
Current	10 A
Efficiency	94%
Features	Adjustable Output, DC Input Capable, PFC, Universal Input
Mounting Type	DIN Rail
Number of Outputs	1
Operating Temperature	-25°C ~ 70°C (With Derating)
Power (Watts)	480W
Size	5.06" L x 3.37" W x 4.93" H (128.5mm x 85.5mm x 125.2mm)
Standard Number	62368-1; UL 508
Type	Enclosed
Voltage	48V
