| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,000 pcs
|
2000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| Current Rating (Typical) | |
| DC Resistance | |
| DC Resistance (DCR) | |
| Frequency | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Resistance to Soldering Heat | |
| Self Resonant Frequency | |
| Shielding | |
| Storage Temperature | |
| Tape & Reel | |
| Tolerance | |
| Type | |
| Width |
The Bourns SDE6603-1R0M is a wirewound, drum core SMD power inductor designed for various electronic applications. It features a ferrite core material and a surface mount package, making it suitable for automated assembly processes.
This inductor provides an inductance value of 1 µH with a tolerance of ±20% and a DC resistance (DCR) of 50mΩ maximum. It has a rated current of 2.9A and a saturation current of 2.9A. The operating temperature range is -25°C to 105°C.
The SDE6603-1R0M has a unit height of 2.92mm and dimensions of 6.60mm x 4.45mm. It is unshielded and designed for reliable performance in demanding environments. The component is supplied on tape and reel in standard quantities of 2000 pieces.
This series is RoHS3 compliant and REACH unaffected, indicating adherence to environmental regulations. Its robust construction and electrical characteristics make it a suitable choice for power supply circuits and other applications requiring efficient energy storage and filtering.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.52 | $0.52 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 1 µH with a tolerance of ±20% at 100KHz.
The rated current (Irms) is 2.9A, and the saturation current (Isat) is also 2.9A.
The maximum DC resistance is 0.05 Ω.
The operating temperature range is -25°C to 105°C.
It is a surface mount package.
The standard package contains 2000 pieces.
