The E-T-A REX12-TA1-107-DC24V-2A is a compact, flexible electronic circuit protector designed for selective overcurrent protection. It offers a 2A current rating and operates at 24VDC, with a solid-state breaker type and a push-to-reset actuator.
This circuit breaker is part of the REX12 series, featuring a module width of 12.5 mm per channel. It is capable of switching capacitive loads up to 20,000µF and includes manual ON/OFF/reset functionality. The device provides clear status indication via LED and a signal contact.
Approved by UL1310, UL2367, and UL508, this circuit protector is suitable for applications requiring reliable overcurrent and short-circuit protection. Its design integrates supply modules, overcurrent protection, and power distribution, minimizing the need for additional accessories and saving installation time and space.
The current rating is 2A.
The voltage rating is 24VDC.
It is a solid state circuit breaker.
It features a push to reset actuator.
It is approved by UL1310, UL2367, and UL508.
It can switch capacitive loads up to 20,000µF.
The width per channel is 12.5 mm.
