| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,280 pcs
|
1280 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connectivity | |
| Core Processor | |
| Core Size | |
| Data Converters | |
| EEPROM Size | |
| Mounting Type | |
| Number of I | |
| Operating Temperature | |
| Oscillator Type | |
| Peripherals | |
| Program Memory Size | |
| Program Memory Type | |
| RAM Size | |
| Speed | |
| Supplier Device Package | |
| Supplier Package | |
| Tape & Reel | |
| Voltage |
The Renesas R7F100GJJ3CFA#BA0 is a 16-bit microcontroller based on the RL78 core, operating at a speed of 32MHz. This device offers 256KB of Flash program memory and 24KB of RAM, along with 8KB of EEPROM.
Key electrical characteristics include a wide operating voltage range from 1.8V to 5.5V. It supports various peripherals such as LVD, POR, PWM, and WDT, and includes data converters with A/D capabilities (12x10b, 8x12b) and D/A capabilities (2x8b). Connectivity options include CSI, I²C, LINbus, SPI, and UART/USART.
This microcontroller is housed in a 52-LQFP package, suitable for surface mounting. The operating temperature range is -40°C to 105°C (TA). It features an external oscillator type.
The R7F100GJJ3CFA#BA0 is designed for embedded applications requiring a balance of performance, memory, and peripheral integration.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.40 | $6.40 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage range is 1.8V to 5.5V.
It comes in a 52-LQFP (10x10) surface-mount package.
The operating temperature range is -40°C to 105°C.
RoHS3 compliance status is unverified; treat as low-confidence.
