| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Group | |
| Center Contact Material | |
| Connector Style | |
| Connector Type | |
| Contact Termination | |
| Fastening Type | |
| Frequency | |
| Housing Color | |
| Impedance | |
| Lead Style | |
| Mounting Feature | |
| Mounting Type | |
| Number of Ports | |
| Shield Termination |
The Radiall R125325000W is an SMA coaxial connector assembly designed for use with RG-402 (.141" semi-rigid) cable. It features a straight bulkhead jack configuration with a female socket contact and threaded coupling for secure connections.
This connector offers a nominal impedance of 50 Ohms and supports frequencies up to 18 GHz, making it suitable for high-frequency RF applications. The center contact is made of beryllium copper, and the housing has a gold finish. Both the contact and shield terminations are solder type, providing reliable electrical connections.
The bulkhead mounting with front side nut allows panel mounting, ideal for enclosure interfaces where a secure, feed-through connection is required. It is commonly used in telecommunications, test equipment, and aerospace systems.
The connector is part of Radiall's SMA product line and offers a durable, high-performance solution for demanding RF environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $44.00 | $44.00 |
| 10+ | $37.40 | $37.40 |
| 30+ | $34.61 | $34.61 |
| 50+ | $33.38 | $33.38 |
| 100+ | $31.79 | $31.79 |
| 250+ | $29.80 | $29.80 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Panel mount with bulkhead front side nut.
50 Ohm.
18 GHz.
Solder termination for both contact and shield.
RG-402 (.141" semi-rigid) cable.
Beryllium copper.
