PCMF3DFN1X The Nexperia USA Inc. PCMF3DFN1X is a 6-line common mode choke designed for signal line filtering with integrated ESD protection. It features a Surface Mount package and operates from -40°C to 85°C.
Mfr Part #:

PCMF3DFN1X

Available from 1 distributors
Mfr Name: Nexperia USA Inc.
Nexperia USA Inc.
The Nexperia USA Inc. PCMF3DFN1X is a 6-line common mode choke designed for signal line filtering with integrated ESD protection. It features a Surface Mount package and operates from -40°C to 85°C.
✓ Total Stock: 460 pcs
$ Price Range: $0.99

PCMF3DFN1X Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
460 pcs
On Request
460 pcs On Request 1 On Request On Request 1347+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PCMF3DFN1X Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
DC Resistance (DCR) (Max)
Features
Filter Type
Height (Max)
Lead Spacing
Length
Mounting Type
Number of Lines
Operating Temperature
Tape & Reel
Width
View Similar Products (0)

PCMF3DFN1X Description

Short technical summary and product information.

The PCMF3DFN1X from Nexperia USA Inc. is a common mode choke filter designed for differential channels with integrated ElectroStatic Discharge (ESD) protection. This device offers superior common-mode suppression over a wide frequency range while maintaining low insertion loss for differential high-speed signals.



Key electrical characteristics include ESD protection up to ±15 kV contact discharge according to IEC 61000-4-2. The filter type is specified for signal lines, and it has a maximum DC Resistance (DCR) of 5 Ohm (Typ). The device supports 6 lines.



Mechanically, the PCMF3DFN1X is housed in a 14-XFDFN package with a maximum height of 0.50mm. Its dimensions are 4.00mm in length and 2.00mm in width. The mounting type is Surface Mount, making it suitable for compact PCB designs.



This component operates within a temperature range of -40°C to 85°C. It is classified as RoHS3 Compliant, has an MSL of 1 Unlimited, and is REACH Unaffected, though these compliance statuses are unverified.

PCMF3DFN1X Quick Information

Product Type: Common Mode Choke
Canonical Name: Common Mode EMI Filter with ESD Protection
Subcategory: EMI Filter

PCMF3DFN1X Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PCMF3DFN1X Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

PCMF3DFN1X Features

  • Common mode EMI filter with ESD protection.
  • ESD protection up to ±15 kV contact discharge.
  • Designed for signal line filtering applications.
  • Surface Mount 14-XFDFN package.
  • Operates from -40°C to 85°C.

PCMF3DFN1X Applications

  • Used for EMI and RFI filtering.
  • Provides downstream ESD protection.
  • Suitable for high-speed differential signals.
  • Integrates common-mode suppression.

PCMF3DFN1X FAQs

5 frequently asked questions generated from this part’s specifications.
What is the ESD protection level for the PCMF3DFN1X?

The PCMF3DFN1X provides ESD protection up to ±15 kV contact discharge according to IEC 61000-4-2.

What is the operating temperature range for this common mode choke?

The operating temperature range for the PCMF3DFN1X is -40°C to 85°C.

What package type is the PCMF3DFN1X?

The PCMF3DFN1X is supplied in a 14-XFDFN Surface Mount package.

What is the maximum DC resistance (DCR) of the PCMF3DFN1X?

The maximum DC resistance (DCR) for the PCMF3DFN1X is 5 Ohm (Typical).

How many lines does the PCMF3DFN1X filter?

The PCMF3DFN1X is designed to filter 6 lines.
