| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
577 pcs
|
577 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Diameter | |
| Color | |
| Diameter | |
| Features | |
| For Use With | |
| Ingress Protection | |
| Material | |
| Mounting Feature | |
| Operating Temperature | |
| Resistance | |
| Shelf Life | |
| Storage Temperature | |
| Tape & Reel | |
| Thread Size | |
| Type |
This APM Hexseal N5030S 1 is a full toggle boot seal constructed from durable silicone rubber, providing robust protection for switches. It features a gray color and is designed for front panel mounting with a 1/4-40 NS-2B thread size.
The boot seal offers excellent environmental protection, rated IP66/IP68, making it dust-tight and resistant to water ingress. It is engineered to withstand operating temperatures from -70°C to +204°C (-94°F to +400°F), ensuring reliable performance in various conditions. The material is resistant to saltspray, sunlight, ozone, weather, fungus, and most acids and lubricating oils.
With a secondary inner seal and a panel sealing rib, this boot forms a watertight and dust-tight seal around the switch bushing. It has an operational life of at least 100,000 actuations and a shelf life exceeding 25 years. The N5030S 1 is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range is -70°C to +204°C (-94°F to +400°F).
The N5030S 1 switch boot has an ingress protection rating of IP66/IP68.
The boot seal is made from silicone rubber.
The thread size for mounting is 1/4-40 NS-2B.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
