The Cinch MS24266R12B12SN is a circular connector plug from the MIL-C-26500 / C48 series, designed for free-hanging in-line mounting. It accommodates 12 power contacts with female sockets and uses crimp termination for secure wire connections.
The connector features a bayonet lock fastening system for quick and reliable mating. The shell is made of aluminum with an anodized finish, and the contacts are gold-plated for corrosion resistance and reliable signal integrity. The cable opening measures 0.580 inches (14.73 mm), and a coupling nut is included.
This connector is rated for an operating temperature range of -55°C to 200°C and is environment sealed, making it suitable for demanding applications. It is unshielded and has a normal (N) orientation.
| Qty | Low | High |
|---|---|---|
| 1+ | $93.33 | $93.33 |
| 2+ | $100.00 | $100.00 |
| 10+ | $79.33 | $79.33 |
| 25+ | $68.99 | $68.99 |
| 26+ | $93.76 | $93.76 |
| 50+ | $63.47 | $63.47 |
| 100+ | $56.67 | $56.67 |
| 250+ | $85.72 | $85.72 |
| 500+ | $82.20 | $82.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It is a plug with female sockets.
It has 12 power positions.
Free hanging (in-line) mounting.
Bayonet lock.
Crimp termination.
-55°C to 200°C.
Aluminum shell with an anodized finish.
