| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
480 pcs
|
480 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connectivity | |
| Core Processor | |
| Core Size | |
| Data Converters | |
| Mounting Type | |
| Number of I | |
| Operating Temperature | |
| Oscillator Type | |
| Peripherals | |
| Program Memory Size | |
| Program Memory Type | |
| RAM Size | |
| Speed | |
| Supplier Device Package | |
| Tape & Reel | |
| Voltage |
This NXP Semiconductors microcontroller, part number MCF52223CVM66, is built around a 32-bit Coldfire V2 core running at a speed of 66MHz. It provides 256KB of FLASH program memory and 32KB of RAM, suitable for embedded applications requiring moderate processing power and memory.
The device operates within a voltage range of 3V to 3.6V and has an operating temperature range of -40°C to 85°C (TA). It includes essential peripherals such as DMA, LVD, POR, PWM, and WDT, along with data conversion capabilities (A/D 8x12b). Connectivity options include I²C, SPI, UART/USART, and USB OTG.
Packaged in an 81-MAPBGA (10x10) format, the MCF52223CVM66 is designed for surface mounting. Its 81-LBGA package designation indicates its physical form factor. The microcontroller features an internal oscillator for timing.
Compliance information indicates RoHS3 compliance, MSL 1 Unlimited, and REACH Unaffected status. The part is identified by DK Part Number 2156-MCF52223CVM66-FRE-ND.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.40 | $6.40 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage is 3V to 3.6V.
The operating temperature range is -40°C to 85°C (TA).
It is supplied in an 81-LBGA package, designated as 81-MAPBGA (10x10) for surface mounting.
The program memory size is 256KB (256K x 8).
The RAM size is 32K x 8.
It uses a 32-Bit Coldfire V2 core.
