M39029/63-368 MIL-DTL-24308 qualified D-Sub socket contact from Cinch. Features machined phosphor bronze contact with gold plating, crimp termination for 20-24 AWG wire.
Mfr Part #:

M39029/63-368

Available from 1 distributors
Mfr Name: Cinch
Cinch
MIL-DTL-24308 qualified D-Sub socket contact from Cinch. Features machined phosphor bronze contact with gold plating, crimp termination for 20-24 AWG wire.
✓ Total Stock: 84 pcs

M39029/63-368 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Tomark Electronics Ltd ✓
Non-Authorised Inventory information
84 pcs
On Request
84 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

M39029/63-368 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Style
Contact Finish
Contact Finish Thickness
Contact Form
Contact Material
Contact Size
Contact Termination
Contact Type
Lead Style
Military Grade
Type
Wire Gauge
View Similar Products (0)

M39029/63-368 Description

Short technical summary and product information.

The M39029/63-368 is a MIL-DTL-24308 qualified D-Subminiature socket contact manufactured by Cinch Connectivity Solutions. It is designed for use in D-Sub connectors requiring reliable signal connections. The contact is machined from phosphor bronze and features a gold plating with a thickness of 50.0 microinches (1.27 µm) for corrosion resistance and reliable electrical performance. It accepts 20 to 24 AWG wire and is terminated via crimp. The contact size is 20. This component is RoHS compliant and suitable for aerospace, defense, and other harsh environment applications. The contact is part of the MIL-DTL-24308 specification, ensuring interchangeability and performance standards.

M39029/63-368 Quick Information

Product Type: D-Sub Socket Contact
Series: MIL-DTL-24308
Canonical Name: MIL-DTL-24308 Qualified D-Sub Socket Contact
Subcategory: D-Sub Contacts

M39029/63-368 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

M39029/63-368 Features

  • MIL-DTL-24308 qualified D-Sub socket contact.
  • Machined phosphor bronze contact with gold plating.
  • Accepts 20-24 AWG wire with crimp termination.
  • Contact size 20 for signal applications.
  • RoHS compliant.

M39029/63-368 Applications

  • Used in MIL-DTL-24308 D-Sub connectors.
  • Suitable for aerospace and defense electronics.
  • Ideal for signal connections in harsh environments.
  • Common in test and measurement equipment.

M39029/63-368 FAQs

7 frequently asked questions generated from this part’s specifications.
What wire gauge does this contact accept?

20-24 AWG.

What is the contact finish?

Gold with thickness 50.0µin (1.27µm).

What is the termination method?

Crimp.

What is the contact size?

20.

What connector style is this contact qualified for?

MIL-DTL-24308 Qualified D-Sub.

What is the contact material?

Phosphor Bronze.

Is this part RoHS compliant?

Yes, RoHS3 Compliant (unverified).
