LTC3616EUDD#TRPBF

The AD LTC3616EUDD#TRPBF is a monolithic synchronous step-down DC/DC converter. It utilizes a current mode, constant frequency architecture, offering a low quiescent current of 75µA in Burst Mode operation. This regulator is designed for applications requiring high efficiency, up to 95%, and low dropout operation with 100% duty cycle capability.

Key electrical specifications include a 6A output current, an input voltage range of 2.25V to 5.5V, and an adjustable switching frequency up to 4MHz. The output voltage accuracy is ±1%, with a minimum output voltage down to 0.6V. The device supports selectable operating modes including pulse-skipping, forced continuous, and Burst Mode operation.

Packaged in a thermally enhanced 24-pin 3mm x 5mm QFN package, the LTC3616EUDD#TRPBF is suitable for surface mount applications. Its features like programmable slew rate on the SW node reduce noise and EMI, making it ideal for noise-sensitive applications. It can also be synchronized to an external clock up to 4MHz.

This regulator is well-suited for point-of-load supplies, distributed power supplies, portable computer systems, DDR memory termination, and handheld devices. The internal synchronous switch enhances efficiency and reduces board space by eliminating the need for an external catch diode.
