The Lattice Semiconductor LFSCM3GA40EP1-7FFAN1020C is a high-performance FPGA from the LatticeSC/M family, designed for demanding embedded applications. It offers a substantial fabric with 40,000 logic elements and 10,000 LABs, complemented by 4.08 Mb of embedded Block RAM.
This FPGA provides 562 I/O pins and supports a wide operating voltage range of 0.95V to 1.26V. Key electrical features include a 700MHz global clock and 1GHz edge clocks, along with 4 to 32 high-speed SERDES channels capable of data rates up to 3.8Gbps. The PURESPEED I/O supports differential signaling up to 2Gbps DDR and single-ended memory interfaces up to 800Mbps.
Designed for surface mount installation, the LFSCM3GA40EP1-7FFAN1020C comes in a 1020-BBGA, FCBGA package. It operates within a temperature range of 0°C to 85°C (TJ). The device integrates features like sysMEM™ embedded Block RAM and sysCLOCK™ Network for robust clock management.
The LFSCM3GA40EP1-7FFAN1020C FPGA features 40,000 logic elements, 562 I/O pins, and 4.08 Mb of RAM. It operates at voltages between 0.95V and 1.26V, with a 700MHz global clock and 1GHz edge clocks.
The operating temperature range for the LFSCM3GA40EP1-7FFAN1020C FPGA is 0°C to 85°C (TJ).
This FPGA is available in a 1020-BBGA, FCBGA package, designed for surface mount installation.
The high-speed SERDES on the LFSCM3GA40EP1-7FFAN1020C FPGA supports performance ranging from 600Mbps to 3.8Gbps.
The LFSCM3GA40EP1-7FFAN1020C FPGA has a total of 4,075,520 RAM bits.
