| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Industrial Grade | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Termination Style | |
| Type | |
| Voltage | |
| Width |
The Cosel LEP240F-24-SNZ32 is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It operates with a wide input voltage range of AC 85-264V and delivers a robust 240W of output power.
This converter provides a single output channel with a voltage of 24V and a current capacity of 10A. It is designed for chassis mounting and features a vertical terminal block for connections. The unit boasts an efficiency of 86% and an isolation voltage of 3kV.
Operating within a temperature range of -10°C to 70°C, the LEP240F-24-SNZ32 is suitable for various environmental conditions. It has received approvals from CE, cURus, and TUV, indicating compliance with safety standards. The dimensions are 222.0mm in length, 95.0mm in width, and 45.0mm in height.
The output voltage is 24V.
The output current is 10A.
The rated input voltage is AC 85-264V.
The operating temperature range is -10°C to 70°C.
It uses chassis mount.
