The Artesyn Embedded Power LCC600 series, including the LCC600-28U-9P24 model, offers fully enclosed, conduction-cooled AC-DC power supplies rated at 600 watts. These units are designed for high reliability and performance across a wide operating temperature range of -40°C to 85°C (baseplate).
The LCC600-28U-9P24 provides a single main output with voltages selectable from 12V, 28V, 36V, or 48VDC, along with a 5VDC standby output capable of supplying up to 1.5 amps. The main output voltage is adjustable for application flexibility. Key features include active power factor correction, I2C/PMBus communication, and AC_OK/DC_OK signals.
Designed for demanding environments, this power supply is suitable for both ITE (Commercial) and Medical applications, meeting stringent safety standards such as UL, CSA, TUV, and CB Scheme. Its enclosed, chassis-mount form factor facilitates integration into various systems. The power supply also boasts high efficiency, typically reaching 93.3% at 230 Vac input and full load.
Compliance includes EMI Class B and EN61000 Immunity. The unit is designed for conduction cooling, enabling fanless operation in many applications. Optional variants for IP65 sealing and 277 Vac input are also available.
The LCC600-28U-9P24 has a total power output of 600W.
The LCC600-28U-9P24 offers a single main output.
The LCC600 series offers main output voltages of 12 VDC, 28 VDC, 36 VDC, or 48 VDC.
The LCC600-28U-9P24 provides a 5 VDC standby output with a maximum current rating of 1.5 A.
The operating temperature range for the LCC600-28U-9P24 is -40°C to 85°C on the baseplate.
The U Suffix supports 90-264 Vac input, while the H Suffix supports 180-305 Vac input.
The LCC600-28U-9P24 complies with safety standards including 60601-1, 60950-1, and 62368-1.
