JANTX1N5619US The JANTX1N5619US is a rectifier diode from Sensitron Semiconductor with a 600V reverse voltage and 1A average rectified current. It features a fast 250ns reverse recovery time.
Mfr Part #:

JANTX1N5619US

Available from 1 distributors
Mfr Name: Sensitron Semiconductor
Sensitron Semiconductor
The JANTX1N5619US is a rectifier diode from Sensitron Semiconductor with a 600V reverse voltage and 1A average rectified current. It features a fast 250ns reverse recovery time.
✓ Total Stock: 2,082 pcs
$ Price Range: $0.40

JANTX1N5619US Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Hybrid Electronics ✓
Non-Authorised Inventory information
2,082 pcs
On Request
2082 pcs On Request 1 On Request On Request 0816 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

JANTX1N5619US Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Capacitance @ Vr, F
Military Grade
Reverse Recovery Time (trr)
Reverse Voltage
SVHC Present
View Similar Products (0)

JANTX1N5619US Description

Short technical summary and product information.

The JANTX1N5619US is a single rectifier diode manufactured by Sensitron Semiconductor. It is designed for general-purpose applications and features a maximum reverse voltage rating of 600V and an average rectified current of 1A.



Key electrical characteristics include a maximum forward voltage of 1.6V at 3A and a reverse leakage current of 500nA at 600V. The diode also boasts a fast reverse recovery time of 250ns, making it suitable for switching applications. Its capacitance is rated at 25pF at 12V and 1MHz.



This component operates within a junction temperature range of -65°C to 175°C. It is supplied in a D-5A package, which is a hermetically sealed glass package with two terminals. The standard package quantity is 100 units, and it is supplied in bulk packaging.

JANTX1N5619US Quick Information

Product Type: Rectifier Diode
Series: Military, MIL-PRF-19500/429
Canonical Name: JANTX1N5619US Rectifier Diode
Subcategory: Rectifier

JANTX1N5619US Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

JANTX1N5619US Estimated Pricing

Qty Low High
1+ $0.40 $0.40

Estimated market price range - modelled values for guidance only, not live distributor offers.

JANTX1N5619US Features

  • 600V maximum reverse voltage rating.
  • 1A average rectified current capability.
  • Fast 250ns reverse recovery time.
  • Wide -65°C to 175°C operating temperature.
  • Hermetically sealed glass D-5A package.

JANTX1N5619US Applications

  • Suitable for general purpose rectification.
  • Ideal for switching power supply circuits.
  • Used in high-frequency applications.
  • Applicable in industrial control systems.

JANTX1N5619US FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum reverse voltage of the JANTX1N5619US?

600V.

What is the average forward current rating?

1A.

What is the forward voltage drop?

1.6V maximum at 3A test current.

What is the reverse recovery time?

250ns.

What package does the JANTX1N5619US come in?

Hermetic sealed D-5A glass package.

What is the operating junction temperature range?

-65°C to 175°C.

What is the reverse leakage current?

500nA at 600V.
