| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
692 pcs
|
692 pcs | On Request | 1 | On Request | On Request | CZL H16 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Configuration | |
| Diode Type | |
| Lead Style | |
| Military Grade |
The JAN1N749A-1 is a unidirectional voltage regulator diode manufactured by General Instrument. This component features a silicon element housed within a glass package, designed for reliable voltage regulation.
Key electrical specifications include a nominal working voltage of 4.3V and a maximum power dissipation of 0.5W. The diode operates with a test current of 20mA and offers a voltage tolerance of ±5%. Its unidirectional polarity and single configuration make it suitable for various voltage regulation applications.
The packaging is described as a long-form, round, glass package with wrap-around terminal form and end terminal position. The case connection is isolated. This diode is classified under the Zener - Single category, indicating its primary function in stabilizing voltage levels.
This part is suitable for applications requiring a stable 4.3V reference or regulation. Its construction and specifications suggest use in general-purpose electronic circuits where precise voltage control is necessary.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal working voltage of the JAN1N749A-1 is 4.3 V.
The maximum power dissipation for the JAN1N749A-1 is 0.5 W.
The voltage tolerance of the JAN1N749A-1 is ±5%.
The JAN1N749A-1 is a Voltage Regulator Diode.
The JAN1N749A-1 has a unidirectional polarity.
The package body material of the JAN1N749A-1 is glass.
