ITS4100S-SJ-N
Infineon
The Infineon ITS4100S-SJ-N is a protected single-channel smart high-side NMOS-power switch. It features a 5V to 34V operating voltage range and a nominal load current of 2.0A.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,340 pcs
|
1340 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Operating Temperature | |
| Package / Case |
The Infineon ITS4200S-SJ-D is a protected single-channel smart high-side NMOS-power switch designed for industrial applications. It features a low typical on-state resistance of 150 mΩ and a nominal load current of 1.2 A, making it suitable for switching resistive, inductive, and capacitive loads in 12V, 24V, and 45V DC systems.
This device is equipped with various protection features including overload protection, current limitation, short circuit protection, thermal shutdown with restart, and overvoltage protection. It also includes diagnostic feedback for overtemperature and short circuit conditions, as well as open load detection in the OFF-state. The switch has a wide operating voltage range from 6V to 52V and an operating temperature range of -40°C to 125°C.
The ITS4200S-SJ-D comes in a PG-DSO-8 package. Its design prioritizes optimized electromagnetic compatibility (EMC) and low standby current, contributing to efficient power management. It is qualified for industrial applications according to JEDEC standards and is RoHS compliant.
The typical on-state resistance is 150 mΩ.
The operating voltage range is 6V to 52V.
The nominal load current is 1.2 A.
The operating temperature range is -40°C to 125°C.
It is supplied in a PG-DSO-8 package.
