BSC900N20NS3G
Infineon Technologies
The Infineon Technologies BSC900N20NS3G is an N-Channel MOSFET from the OptiMOS™ series. It features a 200V drain-source voltage and 15.2A continuous drain current.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
476 pcs
|
476 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Drain to Source Voltage (Vdss) | |
| Mounting Type | |
| Operating Temperature |
The Vishay IRFR220TRLPBF is a robust N-Channel MOSFET suitable for power switching and general-purpose applications. It features a maximum drain-source voltage (Vds) of 200V and a continuous drain current (Id) of 4.8A at 25°C case temperature. The device exhibits a low on-resistance (Rds On) of 800 mOhm at 2.9A and 10V gate-source voltage, contributing to efficient power handling.
With a maximum gate-source voltage of ±20V and a gate threshold voltage of 4V at 250µA, the IRFR220TRLPBF is designed for reliable operation. Its power dissipation capability is rated at 2.5W (ambient) and 42W (case temperature), making it suitable for demanding environments. The MOSFET operates within a temperature range of -55°C to 150°C (TJ).
Packaged in a surface-mount D-Pak (TO-252-3) case, this MOSFET is ideal for applications requiring compact and efficient component integration. The component is supplied in Cut Tape (CT) packaging, facilitating automated assembly processes. Its RoHS status is compliant, and it is classified under Moisture Sensitivity Level 1 (Unlimited).
| Qty | Low | High |
|---|---|---|
| 1+ | $1.67 | $1.67 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum drain-source voltage (Vds) for the IRFR220TRLPBF is 200V.
The continuous drain current (Id) for the IRFR220TRLPBF is 4.8A at 25°C case temperature.
The Rds On is a maximum of 800 mOhm at 2.9A and 10V gate-source voltage.
The operating temperature range for the IRFR220TRLPBF is -55°C to 150°C (TJ).
The IRFR220TRLPBF is supplied in a TO-252-3, D-Pak (2 Leads + Tab), SC-63 package.
The IRFR220TRLPBF is packaged in Cut Tape (CT).
