The Texas Instruments INA213BIRSWR is an analog current sense amplifier designed for high-precision, bidirectional current measurements. It operates with a wide common-mode voltage range, from -0.3 V to 26 V, making it suitable for various applications.
Key electrical specifications include a voltage gain of 50 V/V, a common-mode rejection ratio of 100 dB, and a bandwidth of 80 kHz. The device features a low quiescent current of 0.115 mA maximum and an input offset voltage of ±100 µV maximum. The operating temperature range is -40°C to 125°C.
This amplifier is available in a UQFN package, designed for surface mount applications. The standard package quantity is 3000 units on tape and reel, with a reel diameter of 180 mm and a reel width of 9.5 mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.31 | $0.31 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The INA213BIRSWR has a fixed nominal gain of 50 V/V.
The bandwidth is 80 kHz.
The common-mode voltage range is -0.3 V to 26 V.
The operating temperature range is -40°C to 125°C.
The INA213BIRSWR is offered in a 10-pin UQFN package.
The maximum input offset voltage is ±100 µV.
The minimum common-mode rejection ratio is 100 dB.
