The Infineon IMM101T-046M is a fully integrated, high-performance turnkey motor control system designed for variable speed drives. It belongs to the iMOTION™ IPM family, offering a ready-to-use control solution for permanent magnet synchronous motors (PMSM) and BLDC motors.
Key electrical specifications include a 600V blocking voltage for the high-voltage gate driver, a 15V supply voltage for the gate driver, and 3.3V or 5.0V for the controller supply. The module integrates a 3-phase high-voltage gate driver with bootstrap functionality and power MOSFETs. It supports various control input options and features integrated drive and system protection.
This IPM is housed in a very compact 12x12mm PQFN surface-mount package, minimizing external component count and PCB area. It is qualified for industrial applications according to JEDEC standards.
Potential applications include small and major home appliances, fans, pumps, compressors, and general-purpose variable speed drives.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The gate driver supply voltage is 15 V.
The controller supply voltage options are 3.3 V or 5.0 V.
The high-voltage three-phase gate driver has a 600 V blocking voltage.
The isolation voltage is 1500 V RMS for 1 minute.
The MOSFET on-resistance options are 6 Ω/500 V, 1.4 Ω/650 V, and 0.95 Ω/650 V.
Yes, it has certified drive safety functions according to IEC/UL 60730-1 ‘Class B’.
The IMM101T-046M is in a compact 12x12mm PQFN surface-mount package.
