| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8,367 pcs
|
8367 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Automotive Grade | |
| Color | |
| Connector Type | |
| Contact Termination | |
| Contact Type | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Tape & Reel |
The JAE Electronics IL-AG5-10S-S3C1 is a rectangular connector housing designed for use in automotive and industrial applications requiring reliable wire-to-wire connections. This receptacle housing accommodates 10 female socket contacts in a single row configuration with a 2.50mm pitch.
The housing is constructed for free hanging (in-line) mounting and uses crimp termination for secure wire attachment. It is rated for an operating temperature range of -40°C to 85°C, making it suitable for harsh environments. The green polarized housing helps prevent misalignment during mating.
This connector housing is part of JAE's IL-AG5 series and is designed for use with corresponding pin headers. The polarized design and positive locking mechanism ensure secure mating and prevent accidental disconnection.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.40 | $0.40 |
| 10+ | $0.34 | $0.34 |
| 25+ | $0.31 | $0.31 |
| 100+ | $0.29 | $0.29 |
| 250+ | $0.24 | $0.24 |
| 800+ | $0.23 | $0.23 |
| 5,600+ | $0.20 | $0.20 |
| 10,400+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The IL-AG5-10S-S3C1 has 10 positions in a single row.
The pitch is 2.50mm.
It uses free hanging (in-line) mounting.
The operating temperature range is -40°C to 85°C.
It accepts female socket contacts with crimp termination.
The housing is green.
