STD5NM50-1
STMicroelectronics
The STMicroelectronics STD5NM50-1 is an N-CHANNEL Power MOSFET. It features a 500V breakdown voltage and is housed in a TO-251 package.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,475 pcs
|
1475 pcs | On Request | 1 | On Request | On Request | 10+ | On Request | On Request | |
|
48 pcs
|
48 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Voltage Rating |
The Infineon ICE3BR1065JF is an AC-DC integrated power stage designed for Switched-Mode Power Supplies (SMPS) using current mode control. It features an integrated 650V CoolMOS transistor and a startup cell, operating in frequency jitter mode.
Key electrical specifications include a voltage rating of 650V, a typical switching frequency of 67kHz, and a typical on-resistance of 1Ω at 25°C. The device supports active burst mode for low standby power requirements, achieving less than 100mW. It also includes auto-restart protection for overload, overtemperature, and overvoltage conditions.
The ICE3BR1065JF is available in TO220 FullPak packages, specifically PG-TO220-6-247 and PG-TO220FS-6. These packages are suitable for through-hole mounting.
This component is designed for power management and supply applications, offering high power capabilities due to its low RDSon MOSFET. It is suitable for applications requiring efficient power conversion and low standby power.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The ICE3BR1065JF has a voltage rating of 650V.
The typical switching frequency is 67kHz.
The typical on-resistance is 1Ω at Tj=25°C.
The device achieves standby power requirements of less than 100mW.
Available package types include PG-TO220-6-247 and PG-TO220FS-6.
