GMX-SMT2-S2-88 Surface mount shielded modular jack (RJ45) with 8p8c contacts in right angle orientation. Features a board lock for secure attachment and solder termination.
Mfr Part #:

GMX-SMT2-S2-88

Available from 1 distributors
Mfr Name: Kycon Inc.
Kycon Inc.
Surface mount shielded modular jack (RJ45) with 8p8c contacts in right angle orientation. Features a board lock for secure attachment and solder termination.
✓ Total Stock: 9 pcs
$ Price Range: $1.52 - $2.64

GMX-SMT2-S2-88 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
9 pcs
On Request
9 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

GMX-SMT2-S2-88 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Material
Features
LED Color
Lead Style
Mounting Type
Number of Ports
Number of Positions
Number of Rows
Orientation
Shielding
Tab Direction
Termination
Termination Style
View Similar Products (0)

GMX-SMT2-S2-88 Description

Short technical summary and product information.

The GMX-SMT2-S2-88 is a surface mount modular jack from Kycon Inc. designed for RJ45/Ethernet applications. It features 8p8c (8 position 8 contact) configuration with shielded construction to reduce electromagnetic interference. The connector is oriented at a 90° right angle for low-profile PCB mounting.



The jack uses phosphor bronze contacts with a gold finish for reliable electrical performance and corrosion resistance. It includes a board lock feature that provides secure mechanical retention to the PCB during soldering and use. The surface mount termination style is compatible with automated assembly processes.



This shielded modular jack is suitable for networking equipment, data communication devices, and industrial Ethernet applications where signal integrity and mechanical robustness are required. The tab direction is down, ensuring proper mating with standard RJ45 plugs.

GMX-SMT2-S2-88 Quick Information

Product Type: Modular Connector Jack
Series: GMX-SMT2
Canonical Name: Modular Jack, RJ45, 8p8c, Shielded, Right Angle, Surface Mount
Subcategory: RJ45 Jack

GMX-SMT2-S2-88 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

GMX-SMT2-S2-88 Estimated Pricing

Qty Low High
1+ $2.64 $2.64
10+ $2.24 $2.24
25+ $2.10 $2.10
50+ $2.00 $2.00
120+ $1.88 $1.88
360+ $1.74 $1.74
600+ $1.68 $1.68
1,080+ $1.61 $1.61
2,520+ $1.52 $1.52

Estimated market price range - modelled values for guidance only, not live distributor offers.

GMX-SMT2-S2-88 Features

  • Shielded design reduces electromagnetic interference.
  • Surface mount with solder termination.
  • Right angle orientation for low-profile mounting.
  • Gold plated phosphor bronze contacts.
  • Board lock for secure PCB retention.

GMX-SMT2-S2-88 Applications

  • Ideal for Ethernet network interface cards.
  • Used in industrial control systems.
  • Suitable for data communication equipment.
  • Perfect for embedded networking modules.

GMX-SMT2-S2-88 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the GMX-SMT2-S2-88 have?

It has 8 positions (8p8c) compatible with RJ45/Ethernet connectors.

What is the mounting type of this connector?

Surface mount (SMT).

Is this connector shielded?

Yes, it is shielded.

What is the orientation?

90° angle (right angle).

Does the connector include a board lock?

Yes, it features a board lock for secure PCB mounting.

What contact material and finish are used?

Phosphor bronze contacts with gold finish.

Does this connector have integrated LEDs?

No, it does not contain an LED.
