| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,400 pcs
|
2400 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Delay Time tpd(1) Max | |
| Industrial Grade | |
| Lead Spacing | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Gates | |
| Number of I | |
| Number of Logic Elements | |
| Number of Macrocells | |
| Operating Temperature | |
| Programmable Type | |
| Supplier Device Package | |
| Supplier Package | |
| Tape & Reel | |
| Voltage Supply |
The Intel EPM7256EGI192-20 is an EE PLD belonging to the MAX 7000 family of Complex Programmable Logic Devices. This device features 256 macrocells and 5000 usable gates, providing significant logic density for various applications.
With a pin-to-pin propagation delay of 20 ns and a maximum counter frequency of up to 175.4 MHz, the EPM7256EGI192-20 is designed for high-performance systems. It operates within a supply voltage range of 4.5V to 5.5V and has an operating temperature range of -40°C to 85°C (TA).
The device is available in a 192-PGA package, suitable for surface mounting. It offers 164 user I/O pins, allowing for flexible system integration. The MAX 7000 architecture provides advanced features for programmable logic design.
The EPM7256EGI192-20 operates with a supply voltage range of 4.5V to 5.5V.
The EPM7256EGI192-20 is available in a 192-PGA package.
The operating temperature range for the EPM7256EGI192-20 is -40°C to 85°C (TA).
The RoHS status is RoHS3 Compliant.
The EPM7256EGI192-20 has 256 macrocells.
The maximum propagation delay (tpd) for the EPM7256EGI192-20 is 20 ns.
