| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
35 pcs
|
35 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Control Features | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The EHHD015A0A41Z is an isolated DC-DC converter module manufactured by ABB Power Electronics. It provides a single regulated 5V output with a maximum current of 15A, delivering up to 75W of output power. The converter accepts a minimum input voltage of 18V and features a typical efficiency of 90.5%.
This module includes comprehensive protection features such as overcurrent protection (OCP), overtemperature protection (OTP), overvoltage protection (OVP), and undervoltage lockout (UVLO). It also supports remote on/off control with an active-low enable function, making it suitable for controlled power sequencing in complex systems.
The EHHD015A0A41Z is housed in a standard 1/8 brick package (8-DIP module) with through-hole mounting for reliable mechanical attachment. Its compact dimensions of 57.9mm x 22.9mm x 7.8mm allow for high-density board layouts. The device is rated for commercial ITE (Information Technology Equipment) applications and operates over a temperature range of -40°C to 85°C.
The output voltage is 5V nominal.
The maximum output current is 15A.
The operating temperature range is -40°C to 85°C.
It uses an 8-DIP Module, 1/8 Brick package with through-hole mounting.
Yes, it is listed as RoHS3 Compliant.
It includes overcurrent protection (OCP), overtemperature protection (OTP), overvoltage protection (OVP), and undervoltage lockout (UVLO).
The typical efficiency is 90.5%.
