DTE0648D15
XP Power
The XP Power DTE0648D15 is an enclosed DC/DC converter with +/-15V output and 6W power. It features chassis mounting and an efficiency of 85%.
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The XP Power DTE0624D15 is a 6W DC DC converter designed for ITE (Commercial) applications. This enclosed unit features a chassis mount for easy integration into systems.
Key electrical specifications include dual outputs of +/-15V, each capable of delivering up to 200mA. The converter operates with an efficiency of 85% and has a power rating of 6W. It is designed to function within an operating temperature range of -40°C to 105°C, with derating applied at higher temperatures.
The physical dimensions of the DTE0624D15 are 53.0mm in length, 34.0mm in width, and 26.5mm in height. The product complies with standard 62368-1 and carries approvals from CB and CE agencies. It is also RoHS3 compliant and REACH unaffected.
This DC DC converter is suitable for various commercial applications requiring stable dual voltage power conversion.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The DTE0624D15 provides dual outputs of -15V and +15V.
Each output channel can deliver a maximum current of 200mA.
The DTE0624D15 has a power rating of 6W.
The operating temperature range is -40°C to 105°C, with derating applied.
This DC DC converter uses chassis mount.
